Predicting Comfort of Flame Resistant Clothing
There is simply no substitute for a properly conducted, objectively administered, blind wear test.
- By Scott Margolin
- Jun 01, 2012
Comfort has rapidly become a key factor in the selection of flame resistant (FR) and arc-rated (AR) protective clothing In fact, recent research shows it is more important to wearers and specifiers than any single factor. As we move into the spring and summer, it seems timely to review what is known about comfort and to clear up several common misconceptions.
Comfort cannot be reliably predicted by any single lab test of a fabric or by any series of different fabric tests. This is because comfort is inherently subjective; it is entirely a perception in the mind of the individual wearer and thus defies objective, quantified analysis. This perception differs person to person, day to day, and sometimes even moment to moment.
If you'd like to see real-world evidence, take a look around the next meeting you attend with at least eight to 10 people who were free to dress in whatever they prefer. Although the environmental conditions are the same for everyone in the room, chances are you will observe some people wearing one shirt, others wearing a T-shirt and shirt, and some wearing a T-shirt, shirt, and jacket, vest, or other third layer. Probably you also will see long sleeves and short sleeves, knits and wovens, heavy fabrics and lighter fabrics, etc. Despite identical conditions, there likely will be almost as many fabric weights, layers, and styles as there are people in the meeting.
Two fabric "comfort" characteristics that are routinely and significantly misunderstood are breathability and weight. Relying on quantification of these (or any) fabric properties to predict comfort is unwise; wear tests are by a wide margin the most accurate predictor. Breathability (scientifically speaking) is an expression of the ease with which air can move through a fabric, and it is measured by ASTM D737 - 04(2008)e2 Standard Test Method for Air Permeability of Textile Fabrics. It is defined as the rate of air flow passing perpendicularly through a known area under a prescribed air pressure differential between the two surfaces of a material, and generally expressed as cm3/s/cm2 or ft3/min/ft2. Weight is usually expressed in ounces per square yard or grams per meter. Neither number, alone or together, tells us much about comfort. This is particularly true across fiber types, and especially so when comparing natural fibers to synthetics.
Breathability matters because people dissipate heat first by radiation and second by sweating; sufficient air permeability to accomplish this is important. However, once this threshold permeability has been reached, small and medium differences in air perm data are not generally noticeable to a wearer. Significant differences may be meaningful, but only when all other properties are identical (such as with a fiber type and fabric brand); they are usually lost in the myriad of differences across other fiber types and fabric brands.
When wearers talk about "breathability" of an FR or AR fabric, they are generally thinking about a combination of many fabric and garment characteristics that, in sum, mean they "feel too hot" or they "feel OK" or they "feel good." Air permeability quantifies only one of many relevant characteristics and should not be mistaken as categorically measuring what wearers mean by breathability. In fact, there's a long-standing and effective FR fabric that has a very high air permeability rating, and yet it consistently scores at or near the bottom of wear tests for comfort. It is almost always rated well below other fabrics in "breathability" by wear test participants, despite having much higher air permeability data than many of the other fabrics in the studies.
How can this be? When wearers are asked in follow-up research for the rationale behind this rating, the most common answer is one version or another of "the sweat rolls down my back and puddles in my boots." The wearer's perception is that if sweat isn't being evaporated, it must be due to poor breathability. However, this is really more reflective of the fabric's inability to absorb moisture than it is the textile definition of air permeability. The second most common explanation is that the wear test participants questioned the protection of the lightest garments, wondering how effectively they would insulate against a hazard. They were more comfortable when they felt more protected.
In a similar vein, two garments made of the same fabric brand and weight, and therefore possessing the same air permeability number, were given significantly different breathability ratings by wear test participants who knew the fabrics only as A and B. After interviews, it became apparent they rated fabric A as hotter than fabric B, and therefore their perception was that it was less breathable. The only actual difference was that fabric A was much darker in color than fabric B. Darker colors feel hotter in the sun.
Breathability means something different, and something more, to wearers than it does to textile scientists in lab testing, and is thus essentially impossible to homogenize or objectify. The quantification we do have (air permeability) has been oversold as a differentiator (assuming a sufficient base level), and even large changes are often overwhelmed by other differences between compared fabrics.
If air permeability isn't predictive of comfort, what about weight? The popular misconception is that lighter is better in hot weather, but again, wear tests clearly demonstrate otherwise. In the majority of objectively administered blind wear tests of common FR and AR garments, fabrics that are rated as most comfortable are 1 to 2.5 ounces per square yard heavier than the lightest fabrics in the tests. Conversely, the lightest weight fabrics are frequently at or near the bottom in ratings of overall comfort. People who choose FR and AR garments primarily based on the expectation that light weight equals comfort usually select the lightest shirts on the market, which are generally 4.5-ounce synthetics. It is particularly ironic, then, that many feel it necessary to wear 100 percent cotton T-shirts underneath for softness and/or sweat absorption that lightweight synthetic FR doesn’t provide; at 4.5 ounces per square yard, T-shirts effectively double the total shirt weight.
If lightweight were predictive of comfort, we wouldn't expect to look around that meeting room and see people choosing to wear one, two, and even three layers. We wouldn't expect people to choose 14-ounce jeans instead of 9-ounce slacks or 6-ounce shirts over 4.5-ounce shirts, but they do. And they do so sometimes even within a fabric brand, where the only difference is weight. A wear test conducted by a major U.S. utility in a tropical environment, where the temperature and humidity are high year round, rated a 7-ounce shirt as more comfortable than an otherwise identical 5.5-ounce shirt. When the results were questioned prior to writing a specification, the predominant reason given by the wear test population was that lighter shirts stuck to the body once they got sweaty, making it harder to move around and climb poles, while the slightly heavier fabric was not nearly so prone to do so and was otherwise equally comfortable.
Like air perm, lighter weight rarely correlates to overall comfort across multiple fiber and fabric types because comfort is not a single-issue characteristic, and because there are so many other differences. It might seem reasonable to combine characteristics and identify a fabric that has both. However, even this combination approach fails to have predictive value. Quite recently, a matrix was created ranking fabrics by a combination of light weight and high air permeability. The fabric brands were not named, but the data were from the most popular FR and AR fabrics on the market, plus a surprise entry; there was a single woven fabric that had the best numbers by a wide margin in both categories and overall ... and it was a window screen.
There's much we don't fully understand about comfort, and more that is widely misunderstood. Weight and breathability are just two of a number of these characteristics; this makes intuitive sense when you consider the inherently subjective, individual, and dynamic nature of what makes someone feel "comfortable." Some of these characteristics are indefinable, others are not objectively measurable, and the complex interplay between so many variables multiplies the considerations exponentially. Comfort cannot be judged across a desk or from graphs and charts. It eludes simple quantification. There's only one reliable, proven method for predicting comfort of FR and AR clothing. There is simply no substitute for a properly conducted, objectively administered, blind wear test.
This article originally appeared in the June 2012 issue of Occupational Health & Safety.
Scott Margolin is Vice President of Technical Sales for Tyndale Company. He brings more than 30 years of experience in arc-rated/flame resistant (FR) clothing to his role at Tyndale. He has conducted more than 1,800 arc flashes and nearly 4,000 flash fires at labs in the USA, Canada, Europe, South America, and Asia. He travels and presents globally to share his research and learnings on flash fire, arc flash, and combustible dust hazards to improve worker safety and the fibers, fabrics, and garments used to protect against these hazards. He has authored dozens of technical articles and white papers, given more than a thousand presentations all over the world, and led many webcasts on these subjects. Significantly, he has served as SME (Subject Matter Expert) to OSHA, NFPA, NJATC, ASSP, NECA, and others on a wide variety of FR, PPE, and thermal hazard issues.
