By selecting FR garments that provide protection and comfort, your workers will be more likely to wear them—and wear them appropriately.

FR Compliance vs. Protection: An Important Distinction

As thermal exposure increases, the type of FR fiber and fabric plays an increasingly important role in body burn injury and estimated survivability.

Contrary to popular belief, there is no such thing as a "typical" industrial fire. There are various types and sources of industrial fires, and the duration and intensity can change based on the hazard. Thinking that all, or most, fires last for 3 seconds or less and have the same intensity (2 cal/cm2s) is a common myth.

Other misconceptions include the belief that to simplify the implementation of a flame-resistant (FR) garment program, you need only to stipulate National Fire Protection Association (NFPA) 21121 compliant/certified garments or fabrics.

These myths and misconceptions can influence FR garment selection, putting workers at risk. Therefore, it is important to separate fact from fiction and choose FR garments based on your specific hazards.

There Are No 'Typical' Industrial Fires
Although the industry tends to focus on flash fires, there are four primary types of industrial fires:

  • Flash—rapid burning of vapor cloud
  • Jet—burning of pressurized fuel supply
  • Pool—burning of flammable liquid spill
  • BLEVE (boiling liquid expanding vapor explosion)—explosion and fireball from catastrophic failure of contained liquid

Fuel sources include flammable liquids, flammable gases, and combustible dusts. It is important to remember that the magnitude of every fire is equal to the duration multiplied by the intensity. The duration and intensity are not always the same in each fire and can change based on the hazard.

The duration and intensity of any fire depend on the basics of the fire equation, which includes: quantity of fuel, oxygen availability, ignition temperature/heat, and reaction rate of combustion. The duration, also known as exposure time, can range anywhere from 1 second to the "time to escape," while the intensity, or heat flux, can range from less than 1 cal/cm2s to more than 7 cal/cm2s. These two factors combined can lead to a total heat exposure energy ranging from 1 cal/cm2s to greater than 20 cal/cm2s.

Misconceptions about Flash Fires
Why does the industry tend to focus on flash fires? Flash fire was a common industry term used for fire events when the NFPA and Canadian General Standards Board (CGSB) standards were first developed in 2000. Since then, NFPA 2112 and NFPA 21132 have been moving toward recognizing all fire/thermal hazards, rather than just flash fires. In fact, the wording in the purpose statement for NFPA 2112 and NFPA 2113 has been changed to include the term "short duration thermal exposure." Furthermore, NFPA 2113, 2015 edition, has now updated its title to remove the term "flash fire" and replace it with "short-duration" thermal exposures.

Many people believe that all flash fires are 3 seconds or less. This is simply not true. The Occupational Safety and Health Administration 2010 memo to the oil and gas market indicated flash fires can last up to 5 seconds, exceeding the NFPA 2112 minimum standard. And in research conducted by the U.S. Department of Energy, burn times reached more than 15 seconds. This highlights the need to better understand your specific hazard. A useful reference is "The SFPE Handbook of Fire Protection Engineering,"3 which has vapor cloud fire models that predict flame duration for various flammable gases.

Another common misconception is that all flash fires have an intensity of 2 cal/cm2s. Experimental data from the DOE4,5 has shown the potential for significantly higher values. For example, in the DOE China Lake experiments with liquid natural gas vapor cloud fires, the peak heat flux value was more than 7.2 cal/cm2s over a duration of ~5 seconds. And in the China Lake experiments with liquid propane gas vapor cloud fires, the average heat flux value was 3.3 cal/cm2s over a sustained period of time of 15 seconds.

Origins of the 3-Second Myth
Although using 3 seconds as a "general rule of thumb" is not an accurate way to establish the level of protection that workers need for a specific hazard, it is easy to understand how this 3-second myth became such a popularly held belief.

For example, NFPA 2112 stipulates a 3-second, 2 cal/cm2s exposure using test method ASTM F1930, thermal manikin test, for a key minimum FR performance requirement. What is typically overlooked here is that this is for the minimum FR performance requirement—which is only the starting point for protection.

In the appendix of early editions of NFPA 2113, a flash fire was described as typically lasting 3 seconds, a statement that has since been removed. And in the definition of a flash fire, the Canada standard CGSB 155.20 (2000 edition) states: "typically 3 seconds or less." The CGSB 155.20 standard has not been updated since 2000.

So where did the idea of 3-second duration originate?  In the 1970s, the United States military conducted a test to determine total heat exposure received by pilots escaping through the burning fuel of a helicopter crash. During this test, a sensored and clothed manikin was pulled through a burning pool fire of JP4 jet fuel. The conclusion was that a total exposure of 6 cal/cm2s represented this specific hazard.  There was no reference to a duration.

The manikin test was then developed to provide a repeatable test method that could easily and safely generate the 6 cal/cm2s total energy exposure needed by the military. Propane was used for the test because it is a common, easily controlled fuel that can be adjusted to have a heat flux of 2 cal/cm2s. Applying a heat flux of 2 cal/cm2s for 3 seconds equals the 6 cal/cm2s total exposure energy desired.

The FR industry picked up on the 6 cal/cm2s exposure energy so, in essence, the manikin test established the 3-second duration.

Fires Are Unpredictable: Duration and Intensity Matter
As demonstrated by many real-world incidents and laboratory tests, such as the DOE China Lake experiments cited here, the duration and intensity of an industrial fire can vary greatly based on the hazard. This is a very important point to consider when selecting FR fabrics and garments.

Looking at results of thermal manikin tests conducted on an FR-treated cotton garment and an inherent FR garment, it is easy to see the impact that hazard and garment selection have on survivability. For a 3-second fire at an intensity of 2 cal/cm2s (total exposure energy of 6 cal/cm2s), the predicted body burns only vary by 4 percent, and the probability of survival is 99 percent, regardless of fabric choice. In sharp contrast, for a 4-second fire at 2 cal/cm2s (total exposure energy of 8 cal/cm2s), the predicted body burns vary by 35 percent and the estimated probability of survival from 42 percent for a FR treated garment to 91 percent for an inherent FR garment.

Similar results are seen when the intensity increases—even by such a slight amount. For example, in a 3-second fire at an intensity of 2.36 cal/cm2s (total exposure energy of 7.08 cal/cm2s), the predicted body burns vary by 41 percent and the chance of surviving nearly triples with the inherent FR garment. It is remarkable how such a small intensity increase above the 2 cal/cm2s used in the standard thermal manikin test can have such a drastic impact on FR fabric technology performance and body burn injury.

These results clearly show that as thermal exposure increases, either duration or intensity, the type of FR fiber and fabric plays an increasingly important role in body burn injury, estimated survivability and financial costs.

The Financial Impact
Beyond the physical and mental anguish of a burn injury victim, there can also be significant financial costs.

Per NFPA 2112, a FR garment needs to have less than 50 percent total predicted body burn injury during a 3-second, 2 cal/cm2s intensity exposure in order to pass the thermal manikin test. According to the American Burn Association, a survivor's medical cost associated with a 50 percent burn injury can be more than $700,000. These costs can jump to more than $1 million as the burn injury increases past 70 percent.6 Medical costs are only the tip of the iceberg when considering other potential indirect costs such as OSHA fines, insurance claims, lawsuits, and productivity losses.

Avoid just settling for standard acceptance and short-cutting your FR program. The financial cost of one severe burn injury can offset the cost for a thorough hazard assessment and resulting FR PPE program.

Compliance May Not Mean Adequate Protection
When it comes to fire protection, you need to be prepared for the worst-case scenario, not the best. Being in compliance may not mean adequate protection for your workers.

According to OSHA 29 CFR 1910.132, it is the employer's responsibility to assess the hazard and identify the appropriate FR clothing to protect workers. OSHA 3151-12R 2003 states, "…select PPE that will provide a level of protection greater than the minimum required to protect employees from hazards."

NFPA 2112 provides minimum material performance requirements for FR garments. This consensus standard is primarily for garment manufacturers, not end users. NFPA 2113 was developed primarily for end users to assist in the FR garment and hazard assessment process. This consensus standard is an OSHA-recognized tool for 29 CFR 1910.132. It helps guide fire/exposure hazard assessments and protective garment selection, as well as the care, use, and maintenance of FR garments.

What many people fail to realize is that selecting an FR garment that is NFPA 2112 certified does not mean that you are in compliance with OSHA 29 CFR 1910.132 and NFPA 2113—or that you are providing the appropriate FR garment to meet your specific hazard.

Simply put, the purpose of FR fabrics is to reduce burn injury, provide a wearer escape time, and increase his or her chance of survival. However, all FR fabrics are not created equal, and their performance can vary greatly, as shown in the results of the thermal manikin tests previously discussed.

Do not assume that simply complying with the minimum industry standards (such as NFPA 2112 and CGSB 155.20) will keep you and your workers protected. The bottom line is that you must assess your specific hazards and identify the appropriate FR fabric and garment to meet that hazard. And remember, as thermal exposure increases, the type of FR fiber and fabric plays an increasingly important role in survivability. Don't let myths and misconceptions influence your FR garment selection.

1. NFPA 2112: Standard on Flame-Resistant Garments for Protection of Industrial Personnel Against Flash Fire.
2. NFPA 2113: Standard on Selection, Care, Use, and Maintenance of Flame-Resistant Garments for Protection of Industrial Personnel Against Flash Fire.
3. "The SFPE Handbook of Fire Protection Engineering," Fourth Edition, National Fire Protection Association, 2008, 3-308-3-311.
4. Mudan, K.S., Hydrocarbon Pool and Vapor Fire Data Analysis, U.S. Dept. of Energy, DE85005857, Oct. 1984.
5. U.S. Dept. of Energy, Coyote Series Data Report, LLNL/NWC 1981 LNG Spill Tests, Dispersion, Vapor Burn, and Rapid-Phase-Transition, UCID-19953, Vol 1, Oct. 1983.
6. American Burn Association, 2013 National Burn Repository Annual Report, Version 9.0.

This article originally appeared in the October 2014 issue of Occupational Health & Safety.
