Keys to Optimal Flue Gas Analysis

City Technology's Tom Gurd discusses emissions gas monitoring applications and how the right sensor can improve accuracy and reduce service costs.

• By Jerry Laws
• Oct 01, 2014

City Technology's Tom Gurd, product marketing manager, highlights in this Q&A emissions analysis application needs, trends in the global marketplace, and how analyzer manufacturers can benefit from the latest sensing technologies and add real-world value by enhancing measurement reliability, accuracy and reducing operational costs. Gurd specializes in emissions, environmental, and industrial safety gas sensing. A Honeywell company, City Technology has more than 25 years’ experience pioneering flue gas analyzer sensing solutions.

Q: What are the gases flue gas analyzers detect, and why is detection important?
A: The main products of incomplete combustion are usually CO2, CO, H2, and NO; to ensure safe combustion, we measure CO and the remaining O2 after combustion to calculate a CO:CO2 ratio–the accepted benchmark of performance. Of course, there is much more to understand regarding efficiency or environmental emissions. CO sensors are also sensitive to H2, so in our more demanding markets, we measure the H2 to compensate the CO reading. The combustion process is complex, requiring the right mix ratio, turbulence, temperature, and time for reactants to combine. Poor fuel mixing or too little air produces carbon monoxide (CO) and soot. If the flame temperature is too high, nitric oxide (NO) and nitrogen dioxide (NO2) are produced. A fuel containing sulphur will produce sulphur dioxide (SO2). All of these gases are toxic and indicate inefficient combustion, which is both dangerous and costly in terms of fuel consumption. Oxygen (O2) is essential for combustion, so the gases detected by a typical flue gas analyzer are O2, CO, H2, CO2, NO, NO2, SO2, and H2S.

Q: Why is the gas sensor used so important?
A: There is a lot of focus on the analyzer specification itself, but it's also important to remember that an analyzer is only as effective as the sensors it uses. Because of the risks associated with combustion emissions, safety and reliability are critical. Due to the nature of the typical toxic gas sensor used in a flue gas analyzer, emissions gases and products of combustion can produce cross-sensitivity issues.

Field failures can be dangerous and costly, and lives depend on a good sensing technology. What is less widely recognized are the other economic benefits a gas sensor can bring, by reducing an analyzer’s servicing needs and operational costs. Our long-life oxygen sensors, for example, are designed to work as long and hard as a typical analyzer, compared with a standard O2 sensor with a two-year life expectancy that must be changed two to three times in the life of an instrument.

In a real-world context, a combustion check can take up to 15 minutes and is typically carried out up to eight times in each working day. With improved response times, our new sensors can allow the same combustion check to be carried out in half the time or less. This means much less time waiting for the reading to stabilize–and ultimately a valuable opportunity to carry out more services in the field. Faster response is what engineers really value, as they have to wait less time for the reading to stabilize, which can lead to more accurate readings because they are less likely to take the reading too quickly.

Q: You mention adverse conditions that can affect sensor performance. What are these, and how do benchmark sensors overcome such problems?
A: Flue gas analysis in domestic and light commercial boilers can present a challenge for sensors; they are subjected to high humidity, temperature and pressure changes, corrosive and acidic gases, and cross-sensitivity from emissions gases. This can cause field failures, compromise sensor integrity, and create considerable servicing needs.

Every component in a sensor should be built to a high specification using ultra-resistant materials so they can work effectively in these adverse conditions without affecting accuracy and reliability and deliver the fast response times. Sensor design is essential in achieving this. Long-life oxygen sensors are built using "electrochemical pump" technology, which is proven in the field for four years and provides a viable lead-fee replacement.

A high range CO monitoring application, which traditionally requires a second sensor under EN50379-2, benefits from the use of a robust, high-sensitivity solution. The combination of high-capacity filtration to remove SOx and NOx and auxiliary electrodes to compensate for hydrogen provides the highest reliability.

Q: What should an analyzer manufacturer or engineer look for when selecting a sensor manufacturer?
A: It's important to work with a manufacturer who is a recognized expert in the field of emissions monitoring. The ability for a manufacturer to achieve dependable repeatability should also be a key consideration.

Q: How does the right manufacturer back up its claims?
A: Marketing claims must be substantiated. Ask to see comparisons that back up "best in class" claims. Data speaks for itself: A good manufacturer will be keen to show you how their products shape up to contemporaries'. When it comes to reliable performance stability, testing–both life cycle and field tests–provides the peace of mind that a sensor really is up to the job of emissions monitoring. Always ask to see test data that can prove that what a sensor claims it can do is accurate. Extensive testing is an integral part of the design process, highlighting performance and sensor robustness. The measure of how good we are is how consistent our sensors are when they get to our customers.

This article originally appeared in the October 2014 issue of Occupational Health & Safety.
