Trends in Gas Detection Equipment

As a company that began in the gas detection business in the mid-1990s, we are often asked how things are different now than two decades ago. The anticipated answer is, "Quite a bit."

That's a fair expectation, given that in 1995, most people were not online; 4 megabytes of memory on a computer hard drive was considered sufficient; and a cell phone was, to many, a luxury. But while it is safe to say the advances are not quite to those levels for gas detection equipment, the technology has become more sophisticated and the core elements of gas detection are more efficient, easier to use, and more reliable.

So while it is true that systems have greatly improved, the core part of a gas detection system is still essentially intact. All systems essentially include "plug-and-play" field-replaceable sensors, including PID and infrared; integral sampling pumps with strong sample draw capabilities; up to six gases monitored simultaneously; detecting high or low ppm levels (0-50 and 0-2,000) of VOC gases; % volume capability for CH4 and H2 using a TC (thermal conductivity) sensor; ppm or LEL hydrocarbon detection.

In the early 2000s, the focus was on size: Smaller was better. In the past few years, the focus has been more on ease of use and durability. Today’s detection units are built to last.

Yet there is one improvement on the horizon that will be a game-changer for everyone from facilities managers to Department of Public Works (DPW) workers, firefighters to wastewater management professionals--and that's wireless detection. Gas detection systems with a wireless connection can report directly back to a home office or command post miles away at the first sign of trouble. So, if you have electrical workers or DPW workers on a job underground, they can wear wireless detection units the size of a cell phone and transmit conditions back to headquarters. (This is to comply with OSHA regulations for confined space entry, as well as your organization's standard operating procedures.) This gives them the option of checking gas levels while on the job and the security of knowing that someone back at headquarters has access to the same readings and can alert them to potential dangers.

Now, compare the efficiency of a wireless system to a more traditional gas detection system. In that same scenario--personnel working underground--it would require at least one worker to be stationed at the opening of the hole and monitoring gas levels. If there were a problem below, the worker stationed at the entrance would need to signal his or her co-worker about potential problems.

With a wireless connection, more eyes can monitor underground work and other potentially dangerous work situations. At the same time, the wireless connection improves safety for the worker underground should something go awry because of real-time detection. Eventually, you will see the alarm condition sent directly to the emergency response agency, very much like a fire alarm rings to the local fire department now. This will save lives by reducing the response time to an incident.

Wireless devices also have become an integral part of homeland security efforts. Security personnel equipped with wireless gas detectors ensure the safety of tens of thousands at sporting events, concerts, political conventions, the Olympics, etc., all quietly behind the scenes.

Gas System Maintenance
The advances in gas detection equipment have made detection more efficient, but it has not eliminated the need for periodic maintenance and 24/7 monitoring. Simply put, all gas detection should be tested every 90 days (always following the manufacturer's requirements, as well as complying with all local and federal agencies) to make sure they are still correctly calibrated and responding correctly and that all of the target gases are being detected. Those tests should be done with actual gases traceable to the National Institute of Standards and Technology (NIST) to ensure accuracy and protection from liability.

Unfortunately, many building owners and facility managers feel the investment in a gas detection system to be sufficient or have been told it is sufficient once installed just to have it in their properties. To a degree, you can understand that perspective. A gas detection system is not a small investment. With the installation for a single gas detection unit averaging $1,000, adding a maintenance contract for a new or newer gas system might seem like a luxury. It is absolutely not.

Some facilities managers and business owners go by the mantra that if the gas detection system doesn't detect anything, then nothing is wrong. (Sort of, if it isn't broken….) If you could be 100 percent sure the system was working properly, you can understand that logic. Unfortunately, you can't know a gas detection system is working unless it's tested with the appropriate gases. Because most people do not intentionally have those gases on them in a safe form to test their system, there's no way for them to know whether the system is actually reading gas.

Consequently, by not having a routine maintenance system in place, you can put the health and lives of occupants of your building at risk if your gas detection equipment is not functioning properly. And when it comes to exposure to gases, it takes only one incident to put lives in jeopardy and open up your organization to tremendous liability. In fact, in recent years there have been fatalities at facilities in Salem, Mass. and in Connecticut, as well as numerous other U.S. states where gas detection equipment failed.

The flip side to gas detection equipment's not detecting potential dangerous gases is one that is oversensitive and produces false alarms. This is something that occurs in many facilities. While most of these ambient gases are harmless, it is not unusual for a mis-calibrated or infrequent detection system to be set off by them. This can trigger a very costly chain of events: chaos in the immediate vicinity, emergency personnel dispatched to the scene, evacuation of staff and customers, etc.

Bottom line, a false alarm alone can cost thousands of dollars in lost business, lost man hours, and the price of emergency personnel dispersed to the site, not to mention the bad publicity and lost confidence of those involved, as well as those simply aware of it. And with any false alarm, there always exists the possibility that you are taking emergency personnel away from a real emergency where their services are needed.

When you compare the cost of an annual maintenance plan (roughly $1,000) with the thousands of dollars associated with a wrongful death or liability lawsuit, the investment in a maintenance and monitoring program makes all the sense in the world. Yet it's a conservative estimate that of the buildings that have gas detection systems on their premises, perhaps only 10 percent have an active maintenance program with testing conducted on a quarterly basis. While that may sound rather bleak on the surface, the number actually has gone up during the past few years. Much of that has to do with insurance: With an increased focus on risk management for commercial clients, insurance companies have not only mandated that gas detection equipment be installed, but also offered incentives for maintenance and monitoring contracts with those systems. This trend is likely to continue.

As a building owner or facilities manager, your responsibilities are many. The safety of those who work at and visit your property is perhaps the most important of those responsibilities. You can run a smooth and efficient operation for 20 years with little fanfare. One incident with your gas detection equipment and system can mar that reputation.

Installing a state-of-the-art gas detection system with regular maintenance and monitoring buys you peace of mind, and you just can't put a price tag on that. Perhaps the best trend in gas detection equipment is that more and more building owners are choosing common sense over the bottom line.

This article originally appeared in the February 2014 issue of Occupational Health & Safety.
